Fitment
Honda
- 2004–2009 VTX1300C
- 2002–2007 VTX1800C
Important: This product does not fit VTX1300 R/T/S or VTX1800 R/T/S, Those models are also available in our store.
Available Options
(ITU): LED flashing brake light with integrated turn signals
https://www.youtube.com/watch?v=BSaRurv5k3E
(INT): LED tail light with integrated turn signals
https://www.youtube.com/watch?v=6yRTmksJT9Q
(L): LED tail Light with running and brake Light
(LENS): Lens only
While model-specific instructions are not included, the general wiring guidance below should help ensure a smooth installation. If you have questions or need support, contact us .
Running and Brake Light Instructions (Applies to all taillight versions):
Includes a 1157 dual-contact bulb socket, which directly replaces the original bulb socket.
Wiring Color Reference:
Black: Negative (Ground)
Red: Running Light
Green: Brake Light
Integrated Turn Signals Activation
Connect the yellow wire , or yellow & black wire, to the positive wires for the left and right turn signals to activate the integrated signals.
(Optional) Error Code or Alert Fix
If upgrading from incandescent to LED, you may experience error codes, rapid blinking, or static amber lights, this occurs because LEDs draw less current. To resolve this, replace your factory relay with the included LED relay.
Installation Tips
If the light does not power on, check all wiring and connectors carefully.
Try reconnecting the unit
If it still does not work, use a test light or connect directly to a 12V battery using the wire color guide above.
